Our semiconducting CNT layer technology features a substrate-independent homogeneous assembly process on 200 mm wafer, enabling precise control over the CNT density.

The advanced layer deposition process ensures consistent performance and reliability while significantly reducing materials usage and costs. By tailoring the fine structure, we unlock new possibilities for enhancing device efficiency and functionality.
